特性
40mΩ/70mΩ High-Side MOSFET
Available with Current Limits with Foldback
Operating Range:2.7V to 5.5V
1mS Typical Rise Time
Fast Overcurrent Response -1.5μs (TYPICAL)
Under voltage Lockout
Logic Level Enable Pin, Available with
Active-High or Active-Low Version
No Reverse Current when Power Off
Deglitched Open-Drain Over-Current Flag
Output (FLAG)
Output Reverse-Voltage/Current Protection
SOT-23-5, TSOT-23-6, TDFN2x2-6, WDFN2x2-6,
TSOT-23-6 FC, TSOT-23-5 FC, and MSOP-8
Packages (Halogen Free/Pb Free)
UL Certification_#E232223
CB Test Certification by IEC 60950-1:2005/ EN
60950-1:2006
