| 型號： | G952T63U |
| 廠 商： | 中國臺灣 |
| 品牌/商標: | GMT/致新 |
| 產品類別： | GMT- |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
General Description
The G952 positive 1.8V voltage regulator features the ability to source 1A of output current. The typical quiescent current is 0.48mA.
Familiar regulator features such as over temperature and over current protection circuits are provided to prevent it from being damaged by abnormal operating conditions.
Features
■ Output current in excess of 1A
■ Output voltage accuracy +2.5%/-2%
■ Quiescent current, typically 480μA
■ Internal short circuit current limit
■ Internal over temperature protection
Applications
■ PC motherboard
■ ADSL/Cable Modem
■ Set-Top-Box
■ LAN switch/Hub
■ Broad band access
