| 型號： | G5335QT1U |
| 廠 商： | 中國臺灣 |
| 品牌/商標(biāo): | GMT/致新 |
| 產(chǎn)品類別： | GMT- |
| 聯(lián)系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
Features
■ Ultra-High Efficiency
■ Integrated 8.5mΩ at VCC=5V N-Channel MOSFET for Low Side
■ Integrated 20mΩ at VCC=5V N-Channel MOSFET for High Side
■ No Current-Sense Resistor (Lossless ILIMIT)
■ Quasi-PWM with 100ns Load-Step Response
■ 1% VOUT Accuracy Over Line and Load
■ Programmable Switching Frequency
■ Adjustable Output Range from 0.8V
■ 4.5V to 28V Adapter or Battery Input Range
■ Integrated Boost Switch
■ OVP & UVP
■ Over Temperature Protection (non-latch)
■ Adjustable Soft-Start
■ Power-Good Indicator
Applications
■ Notebook Computers
■ I/O Supply
■ Chipset/RAM Supply as Low as 0.8V
■ Networking Power Supply
