General Description

The G910/G911 positive 3.3V voltage regulator features the ability to source 600mA/250mA+ of output current with a dropout voltage of typically 0.65V/ 0.25V. A low quiescent current is provided. The typical quiescent current is 0.3mA. [+ For μTO-92 & TO-92 package]

Familiar regulator features such as over temperature and over current protection circuits are provided to prevent it from being damaged by abnormal operating conditions.

Features

■ Dropout voltage typically 0.65V/0.25V @ IO =600mA/ 250mA+

■ Output current in excess of 600mA/250mA+

■ Output voltage accuracy ±2%

■ Quiescent current, typically 0.3mA

■ Internal short circuit current limit

■ Internal over temperature protection
