微源半導體 LP6493F 同步降壓調節(jié)器IC

General Description

The LP6493 is a synchronous step down regulator with CC control from a high voltage input supply. Operating with an input voltage 8V~30V, the LP6493 achieves 3.5A continuous output current with excellent load and line regulation. Current mode operation provides fast transient response and eases loop stabilization.

The LP6493 requires a minimum number of readily available standard external components. Other features include cable compensation, programmable current limit and thermal shutdown.

The LP6493 converters are available in the industry standard SOP8 packages.

Features

■ Wide 8V to 30V Continuous Operating Input Range

■ 58mΩ/45mΩ Low RDS(ON) Internal Power MOSFET

■ Up to 93% Efficiency

■ Default 180kHz Switching Frequency

■ Internal Soft Start

■ Output Line Drop Compensation

■ Over-Current Protection (OCP) programmable with External Resistor

■ No Loop Compensation Required

■ Thermal Shutdown

■ Available in SOP-8 Package

Applications

■ Car Charger / Adaptor

■ Pre-Regulator for Linear Regulators

■ Distributed Power Systems

■ Battery Charger
